Features

PET film has excellent mechanical properties, and its strength and toughness are the best among all thermoplastics. Its tensile strength and impact strength are much higher than ordinary films; it has good stiffness and good stability and is suitable for printing, paper bags, etc.

PET shrink film is known for its excellent transparency and barrier properties. After bisynchronous stretching, film transparency is especially high. PET shrink film is used for generic packaging, labeling, special packaging (such as for DVDs), baked goods, keeping fresh fruits and vegetables, and synthetic paper labels.

Specifications

Item Description
Materials BOPVC/BOPP/PLA/PET/PE/PA
Extruder Main screw φ90mm, φ100mm, φ120mm, φ150mm, φ180mm
Auxiliary screw φ35mm, φ55mm, φ75mm
Productivity (max) 600kg/hr
Line Speed (max) 200m/min
Automatic Die Head Product width 2500mm~6000mm
Product thickness 0.03mm~0.06mm
Electronic Controlled Edger 1 Set - Static pressure adsorption forming
Cast Forming Rollers φ300~φ500mm x 2~3set
Longitudinal Stretching Unit 2 Sets
Horizontal Stretching Unit 1 Set - 26m~40m
Auto Thickness Tester 2 set
Corona Treater 2 set
Swing 1 Set - Automatic edger
Haul off Equipment 4 Sets
Rolling Station 2 Sets - Dual spindle center roll

Application

labeling, special packaging (such as for DVDs), baked goods, keeping fresh fruits and vegetables, and synthetic paper labels.
